| Resolution | 5MP |
| Focal length | 1.5mm |
| Aperture | F2.4 |
| Mount | M12*0.5 |
| D.H.V | 210°*210°*195° |
| Image sensor | 1/2.5" |
| Drive Voltage | 3.3V-6V |
| Drive current | 165-240mA |
| Driving time | Driving time 200ms≥h≥60ms |
| Filter thickness | 0.2mm |
| Filter coating | IR film and AR film |
| Switching life | More than 300,000 times |
| Adaptable lens | M12 thread lens |
| Size | 31.35*23.7*9.45mm |
| Window aperture | 7.0*7.0mm |
| Fixing screw distance | 20mm |
| Lead wire | 35±5mm |
| Power supply connector | 1.25mm 2PIN terminal |
| Operating environment | Temperature: -30°C~80°C |
| Humidity: 0~90% | |
| Frame Size | 15mm*12mm*1.25mm |
| Fixing module screws | PB1.9*5 |
