| sensor | 2 million 1/2.9 inch CMOS sensor |
| Supported formats | MJPEG/YUY2 |
| video monitor 525 vidicon video out | MJPEG: 1920*1080 (default), maximum frame rate 30FPS 640*480 640*360 800*600 1024*576 1280*720 1280*960 YUY2: 640X*480 (default) with a maximum frame rate of 30FPS 640*360 |
| camera lens | M12/2.8MM |
| denoise | Supports 2D |
| audio frequency | 1-channel digital silicon microphone |
| External dimensions | Dimensions: 15mm*15mm*22mm |
| source | MAX: 5V 0.130A |
