| Aperture Range | F3.5 |
| Focal Length | 70mm |
| Image sensor | 1/1.7" |
| Mount Type | M12*0.5 |
| Resolution | 12megapixel |
| TTL | 75mm |
| FFL(M) | 7.2mm |
| BFL(O) | 23.1mm |
| OPT Distortion | <-1% |
| Relative III. | >85% |
| Chief Ray Angle | <6% |
| M.O.D | 0.5m~∞ |
| Dimension Figure | 29.0*L67.8mm |
| Lens Structure | 9G |
| waterproof | No |
| Weight | 49g |
| Iris Operation | Fixed |
| Zoom Operation | Fixed |
| Focus Operation | Manual |
| Operating Temperature | -25°~+85° |
| Storage Temperature | -25°~+85° |
