◆Support maximum 1920*1080@30fps HD screen output
◆Support H.264/H.265 coding
◆ Low illumination 0.01Lux/F1.6(Color),0.001Lux/F1.6(B/W)
◆10X 2MP ultra clear optical zoom auto focus lens
◆Support 3D digital noise reduction, wide dynamic, fog transmission, glare suppression, electronic stabilization, etc.
◆Support 360°horizontal rotation, vertical direction 0°~90°.
◆ Support hand control speed: 0.1°-200°/S, preset position speed: 240°/S
◆Support 256 preset positions, 4 groups of track scanning, 8 groups of preset point cruise
◆Support 3D positioning, privacy masking, watchdog bit function
◆Support target counting, retrograde detection, off-duty detection, electronic fence, helmet detection, face recognition ◆Support 2-channel alarm input and 1-channel alarm output, support alarm linkage function
◆Support maximum 128G Micro SD card storage
◆Support SDK, ONVIF, API, GB/T28181 protocol access
◆Lightning protection, anti-surge, anti-surge, IP66 protection leve
◆Support H.264/H.265 coding
◆ Low illumination 0.01Lux/F1.6(Color),0.001Lux/F1.6(B/W)
◆10X 2MP ultra clear optical zoom auto focus lens
◆Support 3D digital noise reduction, wide dynamic, fog transmission, glare suppression, electronic stabilization, etc.
◆Support 360°horizontal rotation, vertical direction 0°~90°.
◆ Support hand control speed: 0.1°-200°/S, preset position speed: 240°/S
◆Support 256 preset positions, 4 groups of track scanning, 8 groups of preset point cruise
◆Support 3D positioning, privacy masking, watchdog bit function
◆Support target counting, retrograde detection, off-duty detection, electronic fence, helmet detection, face recognition ◆Support 2-channel alarm input and 1-channel alarm output, support alarm linkage function
◆Support maximum 128G Micro SD card storage
◆Support SDK, ONVIF, API, GB/T28181 protocol access
◆Lightning protection, anti-surge, anti-surge, IP66 protection leve
| movement | |
| imaging device | 1/2.8″Sony 2.13M CMOS Sensor |
| Minimum Illumination | Color: 0.01 Lux@F1.6; B/W: 0.001Lux@F1.6 |
| Effective Pixel | 2 MP |
| Horizontal Resolution | Greater than 1000TVL |
| Optical Zoom | 10X |
| Digital Zoom | / |
| Focal length | f=4.7mm~47mm |
| Aperture | F1.6(W)~F3.0（T） |
| Field of view | 60.9°（Wide）~6.43°(Tele) |
| Zoom Speed | Adjustable from 1-10 levels |
| Focus Mode | Auto/Manual |
| Focus Area | Full Area/Center Focus |
| Signal-to-noise ratio | ＞50dB |
| Image Adjustment | Support adjustable brightness, contrast, saturation, sharpness |
| White Balance | Auto/User-defined/Lock White Balance/Incandescent/Warm/Natural/Fluorescent |
| Image Mode | Standard/Colorful/Natural |
| Aperture Control | Auto/Manual |
| Exposure Mode | Auto Face Exposure/Manual Exposure Control |
| Electronic Shutter | Auto,Manual(1/25~1/10000),FLK |
| Auto Slow Shutter | Off/On |
| Gain Control | Low/Lower/Medium/High/High |
| Backlight Mode | Strong Light Suppression/Backlight Compensation/Off |
| Dark Zone Compensation | / |
| Exposure Compensation | / |
| Wide Dynamic (WDR) | True Wide Dynamic/Digital Wide Dynamic/Off |
| Day/Night Mode | ICR Switching, Auto/Color/B&W/External Trigger |
| Mirror Image | Normal/Vertical Mirror/Horizontal Mirror/180° Rotation |
| Digital Noise Reduction | Off/Low/Medium/Higher/Higher |
| Fog Transmission | Off/Low/Middle/Higher |
| Electronic stabilization | Off/Low/Middle/Higher |
| audio/video encoding | |
| Video encoding standard | H.264/H.265 |
| H.265 encoding type | Main Profile |
| H.264 encoding type | Base Line / Main Profile / High Profile |
| Frame rate | 1~30 fps adjustable 1920×1080, 1280×960, 1280x720, 720×576 |
| Primary Stream Resolution | 1920×1080(1080p) ，1280x960(960p)，1280x720(720p)，720x576(D1)，640x480(VGA)，352x288(CIF) |
| Secondary Stream Resolution | 720x576(D1)，640x480(VGA)，352x288(CIF) |
| Third Stream Resolution | 1920×1080(1080p)@10fps ，1280x960(960p)@20fps，1280x720(720p)@25fps，720x576(D1)，640x480(VGA)，352x288(CIF) |
| Output Format | PAL/NTSC adjustable |
| Maximum Image Resolution | 1920X1080 |
| Video Bitrate | Fixed bitrate, variable bitrate (16kbps-8000kbps) |
| Stream Type | Composite stream/video stream |
| Audio coding standard | G.711u |
| Audio Bitrate | 64Kbps |
| Audio Control | Input Volume (0-100), Output Volume (0-100) |
| Region of Interest (ROI) | 8 zones |
| Watermark function | / |
| functionality | |
| Horizontal Rotation Range | 360°continuous rotation |
| Vertical Rotation Range | 0°~ 90° |
| Hand speed | 0.1°~200°/sec |
| Preset point speed | 240°/sec |
| Preset Point Accuracy | 0.1° |
| Preset Point | 256 |
| Cruise Scan | 8 Groups |
| Two-point scanning | / |
| Trajectory Scan | 4 groups |
| Continuous Scan | Support |
| Proportional zoom | Automatic |
| Watchdog position | No Motion / Preset Points / Cruise / Track Scanning |
| Auto Flip | Mechanical Flip |
| Power failure memory | Supported |
| 3D Positioning | Supported |
| Multiplier/coordinate display | Supported |
| Infrared Angle | / |
| Infrared distance | / |
| Intelligent infrared | / |
| network | |
| Network Protocols | IPv4,TCP,UDP,HTTP,HTTPS,SMTP,FTP,NTP,DNS,DDNS,DHCP,ARP,UPnP,RTSP,RTP,RTCP, IGMP,PPPoE,ICMP,SNMP |
| Access Protocols | ONVIF GB/T28181 |
| Browser | Support IE11 |
| Number of simultaneous video previews | 8CH |
| User Privileges | User add/delete/modify, administrator/operator/general user |
| Security Mode | Authorized user name and password |
| Motion Detection | Multi-region Sensitivity Multi-threshold selection |
| Masking Alarm | 1 region configurable |
| Privacy masking | 8-area |
| Event Linkage | Capture, TF card recording, FTP upload or send email, alarm output linkage, preset point linkage |
| Multicast Function | Enable/disable multicast |
| Disconnected Network Replacement (ANR) | Support with NVR |
| Cell phone monitoring | Support Apple, Android cell phone monitoring |
| Device anomaly detection | Network disconnection/IP conflict/illegal access |
| Character overlay (OSD) | Title, time and date overlay, OSD color/font size adjustable. |
| Daylight Saving Time (DST) | Support |
| System Upgrade | Support online remote upgrade |
| Others | / |
| AI intelligence | |
| Number of faces detected | Simultaneous detection of 30 static face targets and 10 dynamic face targets |
| Face Size | Face pixels ≥ 80 pixels |
| Posture | Capture within 20 degrees of posture tilt and 20 degrees of left and right. |
| Face De-duplication | Support |
| Face Quality Filtering | Supported |
| Face Dynamic Exposure Adjustment | Support |
| Face library capacity | 10000 |
| Detection area | Full-map detection, support for optional regional settings |
| Upload method | FTP, SDK call upload |
| Human-vehicle detection and analysis 【Open with face function】. | Target Counting, Retrograde Detection, Off-duty Detection, Electronic Fence, Helmet Detection |
| port | |
| Network Interface | RJ45 10M/100M Network Adaptive |
| Analog Video Output | / |
| Audio | 1 input / 1 output |
| Alarm Input | 2 inputs |
| Alarm Output | 1 Output |
| Reset Button | Support |
| RS485 Interface | / |
| TF memory | Maximum 128G |
| Other | / |
| general | |
| Protection class | IP66 |
| Working Temperature | Outdoor: -30℃~50℃ (support low temperature delay 30 minutes to start) |
| Operating Humidity | 10﹪~90﹪ relative humidity (non-condensing) |
| Power supply | DC24V/1.5A (±10%) |
| POE | Support (IEEE802.3AT standard) |
| Power Consumption (Max) | 10W |
| Dimension (mm) | 130(H)×149(D) mm |
| Weight | 2KG |
