| Sensor | OV4689 |
| Lens Size | 1/3 inch |
| Pixel Size | 2.0μmX2.0μm |
| image area | 5440 μmx 3072 μm |
| Max.Resolution | 4.0MP |
| Compression format | MJPEG/YUV2(YUYV) |
| S/N Ratio | 38.3dB |
| Dynamic Range | 64.6dB |
| Sensitivity | 1900mV/lux-sec@550nm |
| Mini illumination | 0.1lux |
| Shutter Type | Electronic rolling shutter/Frame exposure |
| Connecting Port type | USB2.0 High Speed |
| Free Drive Protocol | USB Video Class(UVC) |
| AEC | Support |
| AEB | Support |
| AGC | Support |
| Adjustable parameters | Brightness,Contrast,Saturation, Hue,Sharpness,Gamma, |
| Gain,White balance,Backlight Contrast,Exposure |
|
| Lens Parameter | With a 3.7mm lens |
| Power supply | USB BUS POWER |
| Operating Voltage | DC5V |
| Working current | 150mA~185mA |
| Working temperature | 0-70degree |
| Board size /Weight | 38*38mm |
| Cable | Standard 3 Meter(1m/2m/5m for optional) |
| Operating system request |
Win XP/Vista/Win7/Win8 |
| Linux with UVC(above linux- 2.6.26) |
|
| MAC-OS×10.4.8 or later | |
| Android 4.0 or above with UVC |
