JY-B200W100A 200W solar power pannel with battery set

 Tip: Click on the image to enlarge
Model No.   200W-100AH
SOLAR Parameter Apex Power 200W
Battery Size 125*41.66MM 36pcs 4*9
Power Range + -3%
Apex Voltage 18.17V
Apex Ammeter 3.30A
Short circuit AMM 3.7A
System MAX Volt 1000V
Diode 0by-pass
Solar panel Size 99*76*26CM (composed by 2pcs each set )
BAT work time 100AH, 4-5 days work time
Guarantee 10 years Guarantee 90% Power, 15 years Guarantee 80% Power
General PowerSupply DC12V±10%2A
  Shell Material Aluminum Alloy
Stent Material Aluminum Alloy
Machine Material Aluminum Alloy
Input Volte DC12V 5A Standard
Power Consumption Day: <10W Night:<15w
Work temperature -40°C~+80°C@Humidity10%~95%
Installation method Wall Assembly /Hoisting Assembly
Whole Product Peak Size 99*22*76CM *2 (2 cartons)
Weight 40Kg
ProtectionGrade IP67
ProductSize L99*22*76cm *2(composed by 2pcs)
