MINI-05 720P AHD Camera

 Tip: Click on the image to enlarge


  *1.0MP FHD Mini AHD Camera

  *3.6MM Lens

  *Digital Microphone Supported

  *Signal System: PAL/NTSC

  *Power Supply: DC 12V


Model: MINI-05
Sensor: Cmos Image Sensor
Electronic Shutter: PAL:1/50~1/100000s;
Focus: Manually
Signal System: PAL/NTSC
Resolution: 1280*960
Minimun Illumination: 0.1 Lux
Max Transmission Distance: Common 75-3 lines can be up to 500m
Lens Parameter: 3.6MM Lens,other can be optional
Voltage: DC12V
IR-CUT Filter(IR Filter): Default at 650nm,custom options at 850 or 940nm
IR Illumination: Not Support,can be customized
Night Vision: Not Support,can be customized
S/N Radio: More than 52dB(AGC Off)
Gamma: 0.45/1.0
Exposure: Auto
OSD: Yes
Sync.System: Internal
Video Output: 1xBNC
Audio: Digital Mircophone
Power Supply: DC 12V
Dimension: 15x15mm
Operating Temperature: -20 to 70°C
