Features:
>Alarm indicator: Red led flash
>Test by hand, Auto reset
>Anti-light function
>Strong adaptability of circumstance
>SMT design, high stability
>Sound & flash alarm (independence type)
>RF signal: 433MHz (wireless type)
>ABSplasticmaterial
TechnicalSpecification
| Model | AWL-228W |
| Model type | Wireless smoke detector |
| Power supply | DC9V (6F22 battery) |
| Detection area | 20㎡ |
| Transmitting frequency | 433MHz |
| Transmitting distance | ≤150m(in openarea) |
| Installation height | 1.7 to 2.5m(2.2m is proposed) |
| Sound level | ≤85dB/m |
| Programmer code | 1527 |
| Workingcurrent | ≤10uA |
| Alarm current | ≤30mA |
| Operating temperature | -10℃~ +55℃ |
| Relative humidity | ≤95% RH (non-condensing) |
| Unit size(mm) | 115*115*42 |
