LPR On the road
LPR Parking lot
Main Features：
* High performance multi media processor， SONY professional low lux CMOS
* 1920*1080P Resolution， 60FPS full real time
* 4*white light Array LEDs with stable and reliable property， Luminance decrease less 10% in 3 years
* Strong compatibility， high performance
* 1ch Alarm IN/OUT， Audio，32G TF Card Slot
* 0-120km/h vehicle speed adjustable
| Main Specifications | |||||
| Product Name | Megapixel LPR IP Camera | ||||
| Model | LPR-IPC200F | LPR-IPC200MF4 | LPR-IPC200MF-Z4 | LPR-IPC200MF10 | LPR-IPC200MF-Z10 |
| Image sensor | Sony CMOS sensor | ||||
| Resolution | 1920*1080P | ||||
| Video output | Network | ||||
| Compression | H.264 high profile,M-JPEG | ||||
| FPS | 1920x1080/1-60fps | ||||
| 1280*960/1-60fps | |||||
| 1280*720/1-60fps | |||||
| Compressed code | 256K-12Mbps | ||||
| Dual streaming | Support | ||||
| 3D DNR | Support | ||||
| Network interface | RJ45 ethernet port,10/100M TCP/IP/UDP/RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP supported | ||||
| LPR model | Vehicle speed, environment brightness adjustable | ||||
| Day/night | Auto switching (IR model) | ||||
| LED | White light array LED | ||||
| Lens | 8mm/12mm/16mm HD 3.0MP Lens Optional |
2.8~12mm/ 6~22mm lens HD 3.0MP lens Optional | 2.8~12mm/ 6~22mm HD 2.0MP motorized Zoom and focus lens Optional | 5~50mm lens HD 3.0MP lens | 5~50mm HD 2.0MP motorized Zoom and focus lens |
| Power supply | DC12V(±10%) /POE( IEEE802.3at) | ||||
| Power dissipation | 14W(LED and heater works） | ||||
| Work temperature, humidity | -10℃~55℃,10%~90% RH | ||||
| Temperature control | -5℃ heater(optional), 45℃ fan works | ||||
| Waterproof | IP66 | ||||
| Other features | Audio in/out, alarm input/output, Micro SD card slot for max 32G | ||||
