SMD-4001IPC Pinhole lens wifi ip camera

 Tip: Click on the image to enlarge
  Features:
  24pcs hidden 940nm IR LED, IR Range15m
  H.264 & MJPEG dual-stream encoding
  Max 25/30fps@1080P(1920×1080)
  Day/Night(ICR), 3DNR, AWB, AGC, BLC
  Multiple network monitoring: Web viewer, CMS
  Lens:Pinhole Lens 3.7mm
  IP64
  Wifi /POE/ Audio optional
  Support more than 20 languages Mobile Phone View
  Support P2P Function/DDNS Motion Detection
  Free CMS,Support ONVIF/RTSP
Model SMD-4001IPC-2.0MP
Camera
Image Sensor 2 Mega pixels,1/2.8" SONY CMOS sensor with IR Cut filter
Effective Pixels 1920(H)x1080(V)
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3~1/10000s
Min. Illumination Color: 0. 5Lux, B/W: 0.1Lux ; 0Lux(IR on)
S/N Ratio >50dB
Camera Features
Max. IR LEDs Length > 24pcs 940nm hidden IR LED. IR Range15m
Day/Night Auto(ICR)/Color/B/W
Backlight Compensation BLC
White Balance Auto
Gain Control Auto/Manual
Noise Reduction 3D
WDR Dynamic Range DWDR
Lens
Focal Length Lens:pinhole lens 3.7mm
Max Aperture F1.6
Angle of View 80°
Mount Type MTV mount(Interchangeable Lens)
Video
Compression H.264/MJPEG
Frame Rate Main Stream 1080P (1920*1080) 960p (1280*960)/25fps/HD 720P(1280*720) 25fps
Sub Stream D1 704*576 25FPS / CIF 25FPS
Bit Rate 100kbps-12Mbps, Supports CBR/VBR
Network
Ethernet RJ-45 (10/100Base-T)
Protocol IPV4/IPV6,UDP,RTP,RTSP,RTCP,HTTP,TCP/UDP,DNS,DDNS,DHCP,NTP,PPPOE,SMTP,UPNP,P2P
ONVIF ONVIF Ver.2.4
Max. User Access 10 users
Smart Phone iPhone,iPad,Android
General
Wifi Wifi(IEEE802.11b)
Power Supply DC12V,PoE
Power Consumption <6W
Working Environment -10°C~+60°C,10%~90%
Ingress Protection IP64
Package Weight 0.4KG
Approvals CE FCC RoHS
