| JY-2812CSA-2MP-1/2.7F1.4 | ||||
| Resolution | 2 MegaPixel | |||
| Image format | 1/2.7" | |||
| Focal length | 2.8-12mm | |||
| Aperture | F1.4 | |||
| Mount | CS | |||
| Field Angle | 1/2.7" | D: | H:99° ~ 28° | V: |
| 1/3" | D: | H: | V: | |
| M.O.D. | 0.1M | |||
| Distortion(TV) | <5.1% | |||
| Dimension | φ33×L43.2mm | |||
| BFL | ||||
| TTL | ||||
| Operation | Focus | Manual | ||
| Zoom | Manual | |||
| Iris | Auto | |||
| Lens Material | Metal + Optical Glass | |||
| Weight | 140G | |||
| (Operating Temperature) | .-20℃~+80℃ | |||
