| Pixel | 5.0Megapixel | ||
| ImageFormat | 1/2.5″ | ||
| FocalLength | 6-22mm | ||
| Aperture | F1.6 | ||
| Mount | CS | ||
| FieldAngle | 1/2.5" | 58°×46.4°×34.8°~20.4°×16.3°×12.2° | |
| D×H×V(°) | |||
| M.O.D | 0.3m | ||
| Dimension | Φ33×44.1mm | ||
| Weight | 141g | ||
| FlangBFL | 12.5mm | ||
| BFL | 6.4mm | ||
| MBF | 6.1~8mm | ||
| OpticalDistoration | -6.1%~8% | ||
| Operation | Iris | DC | |
| Focus | Manual | ||
| Zoom | Manual | ||
| Operatingtemperature | -20C+60C | ||
| Sizetolerance(mm) | 0-10±0.5 | ||
| Angletolerance | ±2° | ||
