Feature:
1)Varifocal 2.8-12mm Lens
2)3G/4G SIM Card Slot
3)Strong double antenna 5db
4)SD Card Slot for local storage
5)30pcs F5 IR LED
6)Plug-Play easy Setting (APP: XMEYE)
1)Varifocal 2.8-12mm Lens
2)3G/4G SIM Card Slot
3)Strong double antenna 5db
4)SD Card Slot for local storage
5)30pcs F5 IR LED
6)Plug-Play easy Setting (APP: XMEYE)
| Model No. | JY-IPH3442S-4G/JY-IPH3442E-4G | |
| 4G | Support Network | 4G FDD-LTE/TD-LTE/WCDMA/HSPA+/TD-SWCDMA/GSM/GPRS/EDGE |
| Support Band | B1/B3/B7/B20/B38/B39/B40/B41/B26 | |
| Support Band of frequencies | FDD LTE Band7 / Band3/BAND1/BAND8 | |
| TD-LTE Band38 (2570-2620MHz) / Band39 (1880-1920MHz) / Band40 (2300-2400MHz） Band41 (2496-2690MHz） | ||
| WCDMA/1900/2100/2600MHz | ||
| TD-SCDMA Band34 (2010-2025MHz) / Band39 (1880-1920MHz) | ||
| EDGE/GPRS/850/900/1800/1900MHz | ||
| UMTS Band1 / Band2 / Band5 GSM 900 / 1800 / 1900 MHz | ||
| Network Speed | FDD-LTE/TD-LTE (4G) :150MBPS/50MBPS | |
| WCDMA (3G): 21MBPS/5.76MBPS | ||
| TD-SCDMA (3G): 2.8MBPS/2.2MBPS | ||
| Video | Resolution | 2.0MP(1920*1080P@30/25fps) |
| Video streaming | HD(1920*1080P),VGA(640*360),QVGA(320*180) | |
| Compression standard | H.264 | |
| IR-Cut | Built-in IR Cut.No color deviation indoor and outdoor | |
| Lens Mount | 2.8-12mm Varifocal Lens | |
| Image Frame Rate | 30fps maxmium,downward adjustable | |
| Night Vision | 4Pcs array LEDs,IP distance up to 15 meters | |
| Waterproof | Product Type | Metal Gun type/Waterproof outdoor use |
| Waterproof | IP66 | |
| Network | Ethernet | RJ-45 Ethernet |
| Wireless | IEEE 802.11 b/g/n,Security supports WEP,WPA&WPA2 Encryption | |
| Onvif Protocol | Supports NVR real time monitoring,recording and playback | |
| Alarm | Motion Detection | Yes |
| Alarm Setting | Supports Email,Phone push | |
| Alarm recording | Yes | |
| Storage | MicroSD Card | Supports up to 128G microSD card for recording and playback |
| Recording mode | Manual Record,Alarm Record,Timing Record | |
| View the video | Support Remote video playback | |
| System | For Phone | Support IOS and Android system smart phones or tablet PCs |
| For Windows PC | CMS suports1-,4-,6-,8-,9,16-Channel IP Camera centralized monitor,record and playback on Windows PC | |
| Weight | Package weight | 1.1KG |
| Accessories | Adaptor,User Manual,Bracket,Screw | |
