| Model | JYD-8200(8100)HY-2.0MP | JYD-8200(8100)HY-4.0MP | JYD-8200(8100)HY-5.0MP |
| Image Sensor | 1/2.8" SONY 2.0MP CMOS Sensor | 1/3" OV 4.0 Megapixel CMOS Sensor | 1/3" OV 5.0 Megapixel CMOS Sensor |
| Effective Pixels | 1920×1080 | 2592*1520 | 2592*1944 |
| Min. Illumination | Color : 1.0 lux, BW : 0.5 lux, | ||
| Color DSS : 0.002 lux, BW DSS : 0.0008 lux | |||
| Video Output | Digital : BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/o WDR) | ||
| S/N Ratio | More than 50dB (AGC off) | ||
| Function | |||
| Lens | DC/Manual | ||
| AGC | 0 – 20 steps | ||
| Shutter Speed | AUTO/MANUAL(1/50(60) ~ 1/60,000 sec) | ||
| Digital Slow Shutter | Off/On(x4) | ||
| Brightness | 0 - 20 | ||
| WDR | Off/On(Level Adjustable) | ||
| DEFOG | Off/On | ||
| Day&Night | Auto/Color/B&W | ||
| White Balance | Auto/Auto ext/Pushing/Manual | ||
| 3D.DNR (Digital Noise Reduction) | Off/Low/Middle/High | ||
| AGC | Off/On | ||
| Mirror | Off/On | ||
| Flip | Off/On | ||
| Sharpness | 0 – 10 steps | ||
| Shading | Off/On | ||
| Digital Zoom | 0 – 96 steps | ||
| Privacy Mask | 32 Masks | ||
| Motion Detection | Off/On | ||
| Language | Korean/Chinese/English | ||
| Camera | |||
| Lens Mount | Vari-focal 2.8-12mm | ||
| Infrared Luminary | 36pcs F5 IR-LED | ||
| Infrared Wavelength | 850 nm | ||
| Illuminate Distance | More than 30 M | ||
| Waterproof Criterion | IP 65 | ||
| Video Connector | HD-SDI: BNC connector(SMPTE 292M compatible), CVBS: BNC connector | ||
| Supplied Voltage | DC12V Voltage | ||
| Power Consumption | IR On: 400mA max., IR Off: Less than 130mA | ||
| Dimensions | 200*100*85mm | ||
| Weight | Approx. 0.9kg | ||
