| Model No. | JYD-4400HY-2.0MP | JYD-4400HY-4.0MP | JYD-4400HY-5.0MP |
| Camera Type | AHD （Analog High Definition）Camera | ||
| Effective Pixels | 2.0 Mega Pixels | 4.0 Mega Pixels | 5.0 Mega Pixels |
| Image Sensor | 1/2.8" SONY CMOS Sensor,OSD,ICR | 1/3" OV CMOS Sensor,OSD,ICR | 1/3" OV CMOS Sensor,OSD,ICR |
| DSP | Nextchip 2441H | Nextchip 2475H | Nextchip 2475H |
| Min. Illumination | Color 0.001Lux@F1.2 | Color 0.001Lux@F1.2 | Color 0.001Lux@F1.2 |
| B/W 0.0001 Lux@F1.2 | B/W 0.0001 Lux@F1.2 | B/W 0.0001 Lux@F1.2 | |
| On Screen Display | Yes | Yes | Yes |
| OSD Function |
Manual/DC Lens,Shutter/AGC/WB,Pict Adjust,Mirror,Day/Night,DNR,BLC/HLC,Motion Detect,Privacy Zone
|
||
| IR Cut Filter |
IR LED synchronous switching double filter
|
||
| Lens Mount |
Board lens 3.6mm
|
||
| Infrared Luminary |
24 pieces F5 IR-LEDs
|
||
| Infrared Wavelength |
850 nm
|
||
| Illuminate Distance |
20M
|
||
| Waterproof Criterion |
IP66
|
||
| I/O Connector |
1*DC Power Connector ,1* BNC Video Connector
|
||
| Supplied Voltage |
DC12V
|
||
| Power Consumption |
IR On: 600mA max., IR Off: Less than 200mA
|
||
| Working Enviroment |
-10°C~+60°C, 10%~90% ( Built in Heater being optional added for enviroment lower than -20° )
|
||
| Weight |
1.0kg
|
||
