* 7" full metal body construction, IP66
* ONVIF2.4 ; Compatible with HIKVISION, DAHUA, XM, Video park NVR .etc
* Compatible with CMS,UC2, Milestone, NUUO and AXXON platform.etc
* Intelligent IR illumination & power consumption is variable, dependant the zoom factor
| Specification | |
| Camera | |
| IPC-HD523-EK | |
| Sensor | IMX307 |
| Output Pixel | 1920x1080@20FPS |
| Lens | 20X f=4.7mm~94mm |
| BLC | Support |
| AGC | Auto/manual |
| WB | Auto/manual/indoor/outdoor |
| DNR | 2DNR,3DNR |
| WDR | DWDR |
| S/N Ratio | ≥50dB |
| Dome | |
| Communications Protocol | TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P |
| Software Control | IE, UC2, Management Platform, P2P |
| Mobile View(optional) | Android , iPhone |
| Rotation range | Pan:0~360°,Tilt:0~93º |
| Rotation speed | Pan:0~120°/s, Tilt:0~60°/s |
| Auto Flip | Horizontal 180º,Vertical 93º |
| Preset Points | 220pcs presets（dwell time 01-60s interval available） |
| A-B scan | User programmabel(scan speed 1-64 levels setting available) |
| Guard Tours | 3 groups( Max.16 points, dwell time user selectable) |
| video compression | H.264/H.265M-JPEG |
| audio compression | G711, PCM |
| Operating temperature | -40℃~+60℃ |
| Operation menu | English |
| Power | DC 12V 4A |
| Consumption | ≤25W |
| Lightning Protection | Transient voltage 6000V |
| Related validation | IP66,CE,FCC,RoHs |
