Feature
1,Built-in memory to store the setting data, which can not be lost after power off
2,Continuous 360°pan turning, 90° tilt turning .
3,Variable pan speed-between1-200°/s,Variable tilt speed-between1-180°/s
4, 256 presets, 5 tour routes
5,Support CMS, UC2, Hikvision,, Da Hua, NVR . ONVIF platform access, support for mainstream ONVIF NVR protocol access9,Weather proof design, protection grade IP66
6,Built-in power surge/lightning protection
7,Support IE remote browse their password for remote management, streaming media forwarding phone HD monitor
8,Abnormal automatic recovery, network outages automatically connect function
9,Hardware compression, watchdog, 32M Flash, 128M DDR2.
10,H.264 video encoding,support dual-stream, AVI format; support stream 0.1M ~6Mpbs Adjustable
11,8pcs high brightness laser, night vision distance 150m
1,Built-in memory to store the setting data, which can not be lost after power off
2,Continuous 360°pan turning, 90° tilt turning .
3,Variable pan speed-between1-200°/s,Variable tilt speed-between1-180°/s
4, 256 presets, 5 tour routes
5,Support CMS, UC2, Hikvision,, Da Hua, NVR . ONVIF platform access, support for mainstream ONVIF NVR protocol access9,Weather proof design, protection grade IP66
6,Built-in power surge/lightning protection
7,Support IE remote browse their password for remote management, streaming media forwarding phone HD monitor
8,Abnormal automatic recovery, network outages automatically connect function
9,Hardware compression, watchdog, 32M Flash, 128M DDR2.
10,H.264 video encoding,support dual-stream, AVI format; support stream 0.1M ~6Mpbs Adjustable
11,8pcs high brightness laser, night vision distance 150m
| Camera Specification | ||
| Products Model | IPC-PTZ9002R-20X(1.3MP) | IPC-PTZ9002R-20X(2.0MP) |
| Sensor | 1/3" Progressive Scan CMOS | 1/3" Progressive Scan CMOS |
| Effective pixels | 1280*960 | 1920*1080 |
| Lens | Distance Focus F=4.7mm～84.6mm | Distance Focus F=4.7mm～84.6mm |
| Zoom | 18X optical zoom | 18X optical zoom |
| Output Pixel | 1280*960 25fps | 1920*1080 25fps |
| Coding chip | 1035＋3516C | OV2715 |
| Total pixels | 1.3Megapixels | 2.0Megapixels |
| Synchronous mode | Internal synchronization | |
| Minimum illumination | Color: black and white 0.1Lux: 0.01Lux | |
| Camera OSD display | English menu | |
| Exposure mode | Automatic / manual | |
| mirror function | Support (mirror horizontal + vertical mirror) | |
| Digital noise reduction | 2D Digital noise reduction | |
| Electronic shutter | 1/25s~1/10,000s | |
| PTZ Specification | ||
| PTZ protocol | 1200bps/2400bps/4800bps/9600bps | |
| PTZ address | 1~255 | |
| Horizontal rotary speed | 200°/s | |
| vertical rotary speed | 180°/s | |
| Cruise | Article 5 Cruise | |
| Laser light | 8pcs | |
| Night vision image | soft, bright, standard | |
| guard position | Support | |
| Power off memory | Support | |
| Structure | 4 inch All metal structure | |
| Humidity | ≤95% Non Condensing | |
| Power | DC12V ≤4A | |
| Consumption | < 50W | |
| Lightning Protection | Transient voltage 6000V | |
| Bracket | Standard wall mounting (Hoisting optional) | |
| Weight | 2.0KG | |
| CTN | 205*205*190mm | |
| Related validation | IP66,RoHs | |
