| Model Number | IPC-Kit601PT2A-3.0MP | |
| Wireless Bullet IP Camera Specification: | ||
| Warranty | 2 years | |
| Special Features | NIGHT VISION, Motion Detection, Waterproof / Weatherproof | |
| Sensor | CMOS | |
| Style | Dome Camera, BULLET CAMERA | |
| Function | NIGHT VISION, Waterproof / Weatherproof | |
| Video Compression Format | H.265 | |
| Data Storage Options | NVR | |
| Application | Outdoor, Indoor | |
| Customized support | Online technical support, Customized logo | |
| Image sensor | 1/2.8" 3.0M Pixel CMOS | |
| Lens | 4 mm, horizontal field of view: 75° | |
| Leds | 4pcs dot IR leds,30 meter IR distance | |
| Lens Mount | M12 | |
| S / N ratio | ≥39dB | |
| Shutter speed | 1/5 - 1/20,000s, | |
| Video Compression | H.265 Main Profile/H.264 Main Profile/M-JPEG | |
| Max.Image Resolution | 2048x1536@20fps | |
| Motion detect | Support | |
| Wireless | Frequency:2.4G | |
| Min. Illumination | Color:0.01Lux@(F1.2,AGC ON) B/W:0.001Lux@(F1.2,AGC ON),0Lux @(IRled ON) |
|
| S / N ratio | ≥39dB | |
| Wide dynamic range | Digtal Wide dynamic range | |
| Digital noise Reduction | 2DNR,3DNR | |
| Video Compression | H.265 Main Profile/H.264 Main Profile/M-JPEG | |
| Audio Compression | G711,PCM(optional) | |
| Image Resolution | Main stream (2048x1536,1920x1080,1280×960,1280×720,720×576,640×480) | |
| sub-stream (640×480,352×288,320×240,176×144) | ||
| Bitrate | CBR/VBR, bitrate:32Kbps~10Mbps variable | |
| Privacy Zone Masking | 4 privacy masks programmable | |
| Protocols | TCP/IP,HTTP, NTP,IGMP, DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,P2P | |
| Onvif | Non- Support | |
| NVR Specification: | ||
| Main processor | Hi3536D | |
| Operating System | Embedded Linux | |
| Video compression | H.265 High Profile/ H.264 Main Profile | |
| Video output | 720P 60,XGA,1080P60 | |
| Video input(IP) | 4*1080P/4*960P/4*720P | |
| Audio compression | G.711 | |
| intercom | None | |
| Power supply | DC +12V /3A | |
| Power Consumption | 5W(Without HDD) | |
| Work environment | Temperature:-10℃-+55℃, Humidity:10%-90%RH |
